2.5/3/3.5/4/5 Ton Diesel Forklift Truck, Heli Forklift Co., Ltd

• Overview
• Product Description
• Product Parameters
• Optional Attachment
• Project Case
• Packaging & Shipping
• Company Profile
• Certifications
• Related Products

Overview

Basic Info.

Model NO.	FD30T
Cab Location	Not Adjustable
Type	Diesel Forklift
Power	Diesel Engine
Load Capacity	1T - 5T
Fuel	Diesel
Load center	500mm
Lift height	3000~5000mm
Condition	New
Color	Orange
Product Name	3t Diesel Forklift Truck
Engine	Chinese Xinchia/Quanchai, Japanese Engines
Attachment	Side Shifter, Rotator, Roll Paper Clamp
Transport Package	Standard
Specification	CE\ISO9001: 2008\GOST
Trademark	HECHA
Origin	China
HS Code	8427209000
Production Capacity	3000PCS\Years

Packaging & Delivery

Package Size3.00cm * 1.50cm * 2.50cm Package Gross Weight10000.000kg

Product Description

HECHA construction equipment diesel engine forklift truck 3/4/5 T/ton

√ A perfect combination of power and capacity. √ Consistent, robust, and reliable in the most challenging conditions. √ Able to carry loads ranging from 1.6 to 5 tons, while ensuring rapid turnaround and the utmost efficiency in your warehouse or production facility. √ Offer both powerful performance and genuine cost-effectiveness. √ Extremely maneuverable and transport goods reliably, both indoors and outdoors.

New Compact Mast: Greatly improves the visibility, providing the driver with excellent views of the load and the operating environmentPowerful Engines: helps guarantee excellent driving dynamics with low emissions4-inch Display: Menu is available to be extended, the readable error indicationErgonomic Design: Operator and machine working as one. The operator is able to operate all control elements with minimum effort and utmost precision

Product Description

Product Parameters

Model Name		FD20	FD25	FD30	FD35	FD40	FD50
Power source		Diesel	Diesel	Diesel	Diesel	Diesel	Diesel
Rated capacity	kg	2000	2500	3000	3500	4000	5000
Load center	mm	500	500	500	500	500	500
Mast extended height (with backrest)	mm	4060	4060	4270	4275	4250	4250
Lifting height	mm	3000	3000	3000	3000	3000	3000
Free lift height	mm	140	140	145	150	150	150
Backrest height (from upper face of forks)	mm	1010	1010	1220	1225	1250	1250
Overhead guard height	mm	2090	2090	2106	2106	2350	2350
Overall length (with fork)	mm	3545	3620	3760	3795	4265	4265
Front overhang	mm	435	435	465	465	555	555
Wheelbase	mm	1600	1600	1700	1700	2100	2100
Rear overhang	mm	440	515	525	560	540	584
Ground clearance (bottom of mast)	mm	128	128	145	145	175	175
Overall width	mm	1150	1150	1225	1225	1420	1420
Lateral fork adjustment (outside of fork) (max. / min.)	mm	1024/240	1024/240	1091/250	1091/250	1340/300	1340/300
Front Tread	mm	970	970	1000	1000	1180	1180
Rear Tread	mm	970	970	970	970	1190	1190
Min.right angle stacking aisle width	mm	2200	2280	2380	2400	2900	2900
Tilt of Mast Forward (deg) / Backward (deg)	°	6/12	6/12	6/12	6/12	6/12	6/12
Fork size(LxWxT)	mm	1070×120×40	1070×120×40	1070×125×45	1070×125×50	1070×150×50	1070×150×50
Travel speed (laden / unladen)	km/h	17/19.5	17/19.5	18/19.5	18/19.5	22/22.5	22/22.5
Lifting speed (laden / unladen)	mm/s	570/600	570/600	450/500	380/450	370/400	460/500
Max. Gradeability (laden / unladen)	%	20/20, 21/22	17/18, 18/19	15/18, 19/20	15/18, 15/18	26/17	28/20
Self weight	kg	3320	3680	4280	5950	5950	6400

Optional Attachment

Project Case

Packaging & Shipping

Company Profile

Since 2006, we have been devoted to researching and producing the all-around counterbalance forklifts, to help you raise your intralogistics to a new level and meet your toughest challenges. Our products offer powerful performance and high cost-effectiveness at the same time. With the maneuverable and ergonomic design, our forklifts are able to transport your goods with the utmost reliability, no matter for indoors or outdoors. We have a comprehensive range of products, including diesel forklifts, electric forklifts, LPG & Gasoline forklifts, various pallet trucks and electric stackers.HECHA Assembly LINE Standard Parts are produced by standard mold, which makes the quality and appearance totally the same on different forklifts and shipments. These parts include the counter-balance weight, the chassis, the overhead guard, the engine cover, the seat and etc.

Finished Forklifts Debugging After the production is finished, there is a procedure to debug the forklifts and to check every system. After the debugging, we will make an adjustment to the forklift, to ensure all the forklifts' quality and performance stay at the same level.Become Our Dealer Join us to become our dealer, be ready to serve your clients when they need you, and focus on providing them with proven products and services. Let's Do Some Brilliant Things Together.
